• Door Blade: –  0.6 mm PPGI sheet
• Thickness: – 44 mm.
• Insulation: – High insulating, CFC-free foam.
• Frame: – 2 / 2.5 mm Aluminium profile
• Squeeze Security: – Gasket made of rubber approved for use in the food industry. To be fitted direct to the rear edge of the door blade.
• Hinges: – Made of salt water resistant anodized aluminium and stainless steel. The hinges are maintenance free, no lubrication is required.

• Vision Panel: – Standard sizes:

• 300 x 300 mm
• 400 x 600 mm
• 500 x 600 mm

• Vision panel: – 2- layer thermo glass (standard).
• Min / Max Door Size –  Single Leaf: 1100 mm (W – max.) /  2400 mm (H – max.)
• Double leaf:  2200 mm (W – max.)  / 2400 mm (H – max.)
• Aluminium Kick Plates:  300 mm (standard)
• Bumpers: – Black Polyethylene.
